advantages
Key Features
- Screen ideal for even low flow rates & smaller plants & also available for higher flow rates
- Screening from 1 to 5 mm available as per requirement
- Options of MSEP, SS, MS-FRP available as MOC
- Easy cleaning and low maintenance
- Online operation & thereby removal of solids separated
- Ideal for MBR pre-screening & aqua culture applications
| Type | Inverted Punch hole Rotary, Drum Screen |
|---|---|
| Model | KAS-250/KAS-500/KAS-750/KAS-1000 |
| Light hole, mm | 2.00/option of 0.5, 1.3, 5, 10 available |
| Maximum clean water flow, M3/hr | 114(higher sizes also available) |
| Power, KW | 0.25 |
| Drum raw material | 0.25 |
| Piping | SS |
| Electrical Panel | Optional |
Various Applications
- Pre Treatment of MBR Based Effluent/Effluent Treatment Plants
- Lake or Pond Filtration/screening
- Water Body Filtration
- Process screening for upto 5 mm solids/fibers
- Fisheries as a contaminant removal (Online system)
Available Ranges & Models
- 1 M3/Hr. to 100 M3/Hr
- Option of MOC – Mild Steel Epoxy Painted / Mild Steel Powder Coated / Stainless Steel
- Perforation Sizes Available: 1/2/3/4/5 mm
